Introduction to the Air Arms S410

The Air Arms S410 rightly deserves a place in the ‘airguns hall of fame’, if one were to exist. Though it has been around for several years, a fact borne out by a range that has expanded with new variants, the platform is sturdy, reliable and very effective.

With classic sporting rifle looks and a slick bolt action, the S410 air rifle appeals to traditionalist for whom aesthetics are important. However, it also delivers performance that stands up against just about anything else on the market. The lack of a regulator dates the action, but the efficient design, which has been tweaked and refined over the years, still delivers up to 100 shots in .22.

About Air Arms

Based in south east England and founded in 1983, Air Arms has a long and well-respected reputation. It was one of the early pioneers of modern-day pre-charged pneumatic (PCP) air rifles, introducing its first model in 1988. Today the company produces some of the most respected PCP hunting and competition rifles, as well as class-leading underlever spring-powered rifles.

“it also delivers performance that stands up against just about anything else on the market”

“Though unregulated, the S410 platform has proven itself as reliable and efficient over many years”

“the S410 is designed to look and operate as a hunting rifle in which case the shot count is more than adequate”

S410 Product Range

The S410 range comprises rifle (also known as ‘Classic’) and carbine options. Both have several stock options, a maximum power output of 12 ft. lbs. and share the same bolt action and 10-shot magazine in .177 and .22 calibres. In addition, Air Arms caters for those who prefer the precision of a single shot loader with an S400 model which is available as both a rifle and carbine and are a little lighter than the magazine rifles. The carbine is shorter by 95mm overall and 98.5mm in the barrel and delivers slightly fewer shots as a result. All take a 190-bar fill which is achieved by using a probe that attaches to a valve accessed by removing a cap at the front of the cylinder.

Though unregulated, the S410 platform has proven itself as reliable and efficient over many years. The two-stage trigger is fully adjustable and, paired with a match-grade Walther barrel, is capable of high levels of accuracy. Both the rifle and carbine variants have a manual safety catch located in the trigger blade and are renown for being quiet, especially with a moderator fitted (not standard), making them popular with hunters.

There is very little to criticise about the S410 air rifle series. Being non-regulated, the cylinder design means that shots are limited to a claimed 80 in .177 and 100 in .22 for the rifle and 60/80 for the carbine. That said, the S410 is designed to look and operate as a hunting rifle in which case the shot count is more than adequate.

Air Arms S410 Classic

Also known as the ‘Classic’, the S410 Rifle is offered with several different stock options though all measure 1020mm long with a 493.5mm barrel. At 3.3kgs, the Beech variant is the heaviest. Two Walnut options are available – a traditional stock and thumbhole stock version. Also included in the range are two ‘Superlite’ models in ‘Hunter Green’ and ‘Traditional Brown’. Although they are lighter than the Beech stock, they weigh the same as the Walnut rifles at 2.9kgs. The Superlite models are ambidextrous, however, whilst a left-handed option is available for the Walnut rifle, the Beech and Walnut Thumbhole variants are for right-handed shooters only. The S410 features a 10 shot magazine.

The S400 Rifle caters for those who prefer the precision of a single shot loader rather than a magazine. Although available in the same range of stocks, the S400 Rifle is lighter – three kgs in the Beech stock and 2.7 kgs in the others.

Air Arms S410 Classic Beech

Air Arms S410 Carbine

As you’d expect, the S410 Carbine range is shorter than the Rifle with an overall length of 925mm with a 395mm barrel. The Beech stock is heaviest at 3.1kgs and as with the Rifle, there are two Walnut stock options which include a thumbhole variant, and two ‘Superlite’ models in ‘Hunter Green’ and ‘Traditional Brown’, all of which top the scales at 2.8kgs. Left-handed shooters are limited to either of the two Superlites thanks to their ambidextrous stocks, or ordering a left-hand traditional walnut stock. All feature a 10 shot magazine.

The S400 Carbine caters for those who prefer the precision of a single shot loader rather than a magazine. Although available in the same range of stocks, the S400 Carbine is lighter – 2.8 kgs in the Beech stock and 2.6 kgs in the others.

Air Arms S410 Carbine Walnut

Air Arms S410 TDR for sale second hand

As you may be aware, the S410 TDR, or take-down rifle, is no longer available as a new product. However, it may be possible for you to pick one up from a second hand retailer or marketplace. We suggest first taking a look at the other S410 models in this guide to see if one of them would be a better fit for you. If you’re still interested in picking up a used model, please check out our ultimate guide to second hand air rifles, where we walk you through the process of buying a used air rifle and point out various things to look out for.

Is the Air Arms S410 Right for me?

Best suited to

The S410 air rifle series are designed firmly with hunters in mind and is the sort of rifle that can be slung over the shoulder and carried with ease all day. The action, though a little dated now, is efficient and extremely reliable. The S410 and S400 are equally at home on the range of FT/HFT course.

Pros and Cons

The S400 and S410 are elegant looking, traditional sporting rifles. They are light and compact and extremely comfortable in the shoulder. With a silencer fitted they are also one of the quietest rifles available. With sidelever becoming increasingly popular, some will view bolt actioned rifles as old-fashioned. As a cylinder rifle, shot count is lower than many other rifles, especially as the S400/S410 range is not regulated.

Our Recommended Accessories for your Air Arms S410:

Disclaimer

As an Amazon Associate I earn from qualifying purchases.

I get commissions for purchases made through links in this post.

For more information on the best air rifle scopes, pellets, night visions and scopes under £150 do check out our full articles here:

Air Arms S410 Specifications

S410 Classic

S410 Rifle Beech S410 Rifle Superlite Hunter Green S410 Rifle Traditional Brown S410 Rifle Walnut S410 Rifle Walnut Thumbhole
Weight 3.3 kgs 2.9kgs 2.9kgs 2.9kgs 2.9kgs
Length 1020 mm 1020 mm 1020 mm 1020 mm 1020 mm
Barrel 493.5 mm 493.5 mm 493.5 mm 493.5 mm 493.5 mm
Trigger Two stage adjustable Two stage adjustable Two stage adjustable Two stage adjustable Two stage adjustable
Magazine 10-shot. One supplied 10-shot. One supplied 10-shot. One supplied 10-shot. One supplied 10-shot. One supplied
Shot count .177/.22 80 / 100 80 / 100 80 / 100 80 / 100 80 / 100
Air cylinder capacity 216 cc 216 cc 216 cc 216 cc 216 cc
Fill pressure 190 bar 190 bar 190 bar 190 bar 190 bar
Safety catch Manual resettable Manual resettable Manual resettable Manual resettable Manual resettable
½ inch UNF thread Yes Yes Yes Yes Yes

S410 Carbine

S410 Carbine Beech S410 Carbine Superlite Hunter Green S410 Carbine Traditional Brown S410 Carbine Walnut S410 Carbine Walnut Thumbhole
Weight 3.1 kgs 2.9kgs 2.9kgs 2.9kgs 2.9kgs
Length 925 mm 1020 mm 1020 mm 1020 mm 1020 mm
Barrel 395 mm 493.5 mm 493.5 mm 493.5 mm 493.5 mm
Trigger Two stage adjustable Two stage adjustable Two stage adjustable Two stage adjustable Two stage adjustable
Magazine 10-shot. One supplied 10-shot. One supplied 10-shot. One supplied 10-shot. One supplied 10-shot. One supplied
Shot count .177/.22 60 / 80 60 / 80 60 / 80 60 / 80 60 / 80
Air cylinder capacity 155 cc 155 cc 155 cc 155 cc 155 cc
Fill pressure 190 bar 190 bar 190 bar 190 bar 190 bar
Safety catch Manual resettable Manual resettable Manual resettable Manual resettable Manual resettable
½ inch UNF thread Yes Yes Yes Yes Yes

Comparison with the Air Arms Range

Air Arms S410 vs S400

The S400 Carbine caters for those who prefer the precision of a single shot loader rather than a magazine. Although available in the same range of stocks, the S400 Carbine is lighter – 2.8 kgs in the Beech stock and 2.6 kgs in the others.

Air Arms S410 vs S510

The S400 Carbine caters for those who prefer the precision of a single shot loader rather than a magazine. Although available in the same range of stocks, the S400 Carbine is lighter – 2.8 kgs in the Beech stock and 2.6 kgs in the others.

Other Air Rifles to Consider

The Daystate Huntsman compares to the S410 as a traditionally styled, bolt-action sporting rifle and has the benefit of having a regulated model. Unless it really has to be a bolt-action, take a look also at the sidelever Air Arms S510 and the Weihrauch HW100.

Daystate

Air Rifles Brand Guide

Air Arms S510

Air Rifle Series Guide

Weihrauch HW100

Air Rifle Series Guide

Air Arms S410 Dissassembly

air arms s410 disassembly 01

Here you will find disassembly diagrams and part references taken from the official manual for the Air Arms S410 Carbine at https://www.air-arms.co.uk. All credit for producing these diagrams is attributed to Air Arms.

air arms s410 disassembly 02
air arms s410 disassembly 03
air arms s410 disassembly 04
